400 Watt Solar Micro Inverter, Grid-tie Inverter

  • Brand Name:VOLKER
  • Product Name:Micro Inverter
  • Model No.:VMI-400W
  • Recommended Components:1*435Watt
  • Ouput Voltage:120/230V Adaptive
  • Rated Output Power:400 Watt

400 watt grid tie solar micro inverter using IP65 waterproof streamline design, can effectively prevent rainwater on the surface erosion. It can better track the change of solar luminosity and control different output power by the MPPT function, to effectively capture and collect sunlight. It can also automatic shift local grid voltage to 120V or 230V AC output.(get price)



Parameter List

Model VMI-400W
Maximum input power 1*435 Watt
Output voltage mode 120/230V auto switch
PV Open circuit voltage 30-54VOC
Operating voltage range 22-60V
Starting voltage range 22-60V
Short-circuit current 20A
Maximum working current 18A
Output Parameters @120V  @230V
Output peak power 400 Watt 400 Watt
Rated output power 380 Watt 380 Watt
Output current 3.33A 1.74A
AC voltage range 80~160VAC 180~280VAC
AC frequency range 48~51Hz/58~61Hz 48~51Hz/58~61Hz
Power factor >95% >95%
Number of branch connections 15pcs(single phase) 30pcs(single phase)
Output Efficiency @120V @230V
Static MPPT efficiency 99.5% 99.5%
Max output efficiency 95% 95%
Loss of power at night <0.5W <0.5W
Total current harmonics <5% <5%
Appearance and technical features
Temperature range -40℃ to +65℃
Size(L×W×H) 165*176*38mm
Net amount 0.8kg
Waterproof grade IP65
Heat dissipation mode Self-cooling
Communication mode WiFi
Power transmission mode Reverse transmission,load priority
Monitoring System Mobile phone APP
Electromagnetic compatibility EN50081.part1 EN50082.Part1.CSA STD.C22.2 No.107.1
Power grid EN61000-3-2 EN62109.UL STD.1741
Power grid detection DIN VDE 0126 IEEE STD.1547.1547.1 and 1547.A
Certificate CE, Patented technology
Packing weight
Specifications Each(Packing) Box(15pcs)
Weight 1.28KG 19.2KG
Size 245*202*60mm 450*395*345mm



01-----Housing

02-----Micro inverter fixing fole

03-----22-60VDC input (+) connected to PV module

04-----22-60VDC input (-) connected to PV module

05-----Antenna

06-----120/230VAC output connect to grid



1. Who are we?
We are based in Wuhan, China, and started in 2012. We sell to America(25.00%), Europe(25.00%), Africa (15.00%), the Middle East(15.00%), Asia(10.00%), and the Domestic Market(10.00%). Our company has about 200 people.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;


3. What can you buy from us?
Hybrid inverters, microinverters, pure sine wave inverters and pure sine wave inverter PCBA, etc.;

4. Why should you buy from us not from other suppliers?
12 years of experience in the power inverter industry
20 Professional engineering teams
Specialization enhances quality
Two-year warranty and lifetime technical service
Products have passed CE, RoHS, and ISO9001:2000 Quality System Certificates.


5. What services can we provide?
Accepted Delivery Terms: FOB, EXW;
Accepted Payment Currency: USD, HKD, CNY;
Accepted Payment Type: T/T, Cash;
Language Spoken: English, Chinese


Tips: Many low-cost solar inverters are assembled in small unlicensed workshops to reduce costs. The use of substandard components for assembly poses a very big security risk! To protect the pro's personal and property safety, please do not covet low prices; be sure to choose a reliable inverter!
